Doors and Endgate Page 8–1
Page 8–1
Section 8
Doors and Endgate
ATTENTION
Before performing any Service Operation or other procedure described in this Section, refer to Section 2
Precautions, and Section 00 Warnings, Cautions and Notes in the MY 2004 VY Regular Cab and Crew Cab
Service Information for correct w orkshop practices with regard to safety and/or property damage.
The body structure of VY Regular Cab and
Crew Cab vehicles has been developed using
complex design and d evelopment techniques.
In addition to meeting all required standards,
the vehicle body is also a critical part of the
overall safety systems. It is therefore
imperative the repair procedures described in
this Supplement are adhered to during all
vehicle body repairs.
1 General Information ...............................................................................................................................2
Doors and Endgate Page 8–2
Page 8–2
1 General Information
The front door assemblies fitted to VY Regular Cab and Crew Cab vehicles carry over from MY 2003 VY Series vehicles.
The rear door assemblies fitted to VY Crew Cab vehicl es are unique in shape, however service procedures are the same
as the rear door assemblies fitted to MY 2003 VY Sedan vehicles.
The endgate assembly fitted to VY Crew Cab vehicles carries over from MY 2003 VY Utility vehicles.
For body structure repair information on doors and endgate, refer to Section 8, Doors, Liftgate & Endgate in the MY 2003
VY and V2 Series Service Information Supplement, Body Structure Rep air.
