SECTION A - GENER AL INFO RMATION

IMPORTANT

Before performing any Service Operation or other procedure described in this Section, refer to Section 00

CAUTIONS AND NOTES for correct workshop practices with regard to safety and/or property damage.

1. GENERAL INFORM ATION

The HSV GTO and GTS Series Coupe is a new coupe (2-door) body design based on the Holden V2 Coupe.

Sheetmetal for HSV GTO and GTS Series Coupe is carry over from the Holden V2 Series Coupe.

Other changes for HSV GTO and GTS Series Model include:

• HSV designed side skirts.

• HSV designed front and rear bumper fascias.

• New two passenger rear seat.

• New eight-way EZ Entry front seats, with EZ Entry memory type drivers seat.

• HSV designed floor mats.

• HSV door sill appliqué.

• GTS models are fitted with HSV tuned Touring Suspension.

• GTS models are fitted with HSV tuned Performance Suspension.

The powertrain combinations available for HSV GTO Series Coupe carry over from HSV VX Clubsport Series II

Models. The powertrain combinations for HSV GTS Series Coupe carry over from HSV GTS VX 300 kW Series

Model.

NOTE: When using a trolley jack to raise the vehicle it is important that the jack be positioned under the

suspensio n cross-m ember, or ho ist pad locat ions (1). Do not jack under the sus pension contr ol arm. T he vehicle

should always be supported by jack stands at the hoist pad locations when raised. Care must be taken not to

damage the side skirts when jacking the vehicle.
