HOLDEN SPECIAL VEHICLES
SERVICE MANUAL SUPPLEMENT
SECTION A
GENERAL INFORMATION
CAUTION:
HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS
consists of seat belt pre-tensioners (fitted to all front seats), a driver’s-side air bag, a
passenger’s-side air bag and left and right hand side air bags. Refer to CAUTIONS,
Section 12M Occupant Protection System in the MY 2005 VZ Series Service
Information before performing any service operation on or around SRS components,
the steering mechanism or wiring. Failure to follow the CAUTIONS could result in
personal injury or unnecessary SRS system repairs.
2
SERVICE MANUAL SUPPLEMENT
GROUP 0A - GENERAL INFORMATION
The HSV VZ 15th Anniversary Maloo is a limited edition of 50 vehicles based on the
VZ Maloo R8. The service information following applies to the features specific to the
HSV VZ 15th Anniversary Maloo. For all other information refer to Holden VZ or
HSV VZ Maloo R8 Service Information
HSV Modified Performance Suspension
The HSV VZ 15th Anniversary Maloo contains the following features:
Devil Yellow Paintwork
Open Mesh type Fender Vents
HSV Yellow Spirit 19 x 8 SV6000 Alloy wheels
HSV Premium Brake System with Red callipers
Specific 15th Anniversary Maloo badgeing
HSV M
3
1. HSV BUILD PLATE
HSV vehicles can be identified by the HSV Vehicle Build Plate, which is mounted in
the engine compartment. An example of an HSV Build Plate is shown on Drawing
1A2F050010.
4
1A2F050010
BUILD PLATE - VZ Maloo
15th ANNIVERSARY
DP
GD
08.11.05
Maloo R8
NUMERICAL VEHICLE BUILD NUMBER
HSV MODEL DESIGNATION
VEHICLE IDENTIFICATION NUMBER
HSV VEHICLE BUILD DATE
VEHICLE BODY PAINT COLOUR
VEHICLE BODY ACCENT PAINT COLOUR
DATE
ISSUE DATEDISSUE DATED
AUTH'YAUTH'Y
CK.
SYM
AUTH'YAUTH'Y
REVISION RECORDREVISION RECORD
DATE
SYM
SIGNATURES ONSIGNATURES ON
ORIGINAL APPROVALORIGINAL APPROVAL
DR.
ADVANCED AUTOMOTIVE DESIGN AND ENGINEERINGADVANCED AUTOMOTIVE DESIGN AND ENGINEERING
INSTRUCTION DRAWING.INSTRUCTION DRAWING.
A4
SIZE
REVISION RECORDREVISION RECORD
PRELIMINARY ISSUEPRELIMINARY ISSUE
CK.
NAME
PART NO.PART NO.
CK.
REFERENCE
DWG.DWG.
DR.
DATE:
APPR
APPR
DR.
AP
0001
L123456
01/10/05
DEVIL YELLOW
OF THUNDEROF THUNDER
15 YEARS
