HOLDEN SPECIAL VEHICLES

SERVICE MANUAL SUPPLEMENT

SECTION D

BRAKES

CAUTION:

HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS consists of seat belt pre-

tensioners (fitted to all front seats), a driver’s-side air bag, a passenger’s-side air bag and left and right hand

side air bags. Refer to CAUTIONS, Section 12M Occupant Protection System in the MY 2005 VZ Series

Service Information before performing any service operation on or around SRS components, the steering

mechanism or wiring. Failure to follow the CAUTIONS could result in personal injury or unnecessary

SRS system repairs.

2

PURPOSE

The purpose of this section is to provide information on the Brake System fitted to HSV VZ 15th Anniversary

Maloo models.

NOTE:

If specific technical data on a HSV model is not contained in this supplement, obtain data for that model from

Section 5A – Standard Brakes of the VZ series Service Information. References are made throughout this section

to Holden Service Information to assist in providing information for specific service operations.

CAUTION:

When hoisting (or jacking) HSV models, ensure that the lifting head of the hoist lifts on the chassis before the arm

of the hoist contacts the side-skirt

3

BRAKES

1. GENERAL

The brake system fitted to HSV VZ 15th Anniversary Maloo model is the HSV Premium system as fitted to HSV

VZ Maloo R8 models. For all service information on HSV VZ 15th Anniversary Maloo brakes refer to HSV VZ

Maloo R8 Service Information.

CAUTION:

Whenever any component of the ABS is disturbed during service operations, it is vital that the complete ABS is

checked using the procedure detailed in the relevant Holden Service Manual
