Transmission Page F-1
Page F-1
Section F
Transmission
ATTENTION:
HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS consists of seat belt pre-
tensioners (fitted to all front seats), a driver’s-side air bag , a passenger’s-side air bag and left an d right hand
side air bags. Refer to CAUTIONS, Section 12M, in Volume 12M of the Holden V2 Coupe Service Manual
before performing any service operation on or around SRS components, the steering mechanism or wiring.
Failure to follow the CAUTIONS could result in personal injury or unnecessary SRS system repairs.
1 Transmission - General Information ....................................................................................................2
Transmission Page F-2
Page F-2
1 Transmission - General
Information
The transmission, transfer case and front final drive fitted to HSV Coupe 4 models are all HSV Avalanche XUV
components. The transmission is the heavy duty 4L65E as fitted to HSV Avalanche XUV models. For all General
Information and Servicing Operations on these components refer to Section F Transmission in the HSV Avalanche XUV
Service Information.
