C Suspension Page C-1
Page C-1
Section C
Suspension
ATTENTION:
HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS consists of seat belt pre-
tensioners (fitted to all front seat s), a driver’s-side air bag, a passeng er’s-side air bag and left and right h and
side air bags. Refer to CAUTIONS, Section 12M Occupant Protection System in the MY 2005 VZ Series
Service Information before performing any service operation on or around SRS components, the steering
mechanism or wiring. Failure to follow the CAUTIONS could result in personal injury or unnecessary SRS
system repairs.
1 Purpose...................................................................................................................................................2
C Suspension Page C-2
Page C-2
1 Purpose
The suspension system fitted to the HSV VZ Clubsport Murph Edition is the HSV Performance System comprising
increased rate progressive front and rear springs springs and matched damper calibrations, HSV linear steering rack,
HSV power steering oil cooler and a front strut tower brace. These components are all described in the HSV VZ
Clubsport R8 Service Information. T herefore for all service information (inclu ding FWA specs) on the HSV VZ Clubsport
Murph Edition suspension components refer to HSV VZ Clubsport R8 Service Information and Holden VZ Service
Information.
NOTE
If specific technical data on a HSV model is not
contained in this supplement, obtain data for that
model from the relevant Holden VZ series
Service Information Supplement. Refer ences are
made throughout this section to Holden Service
Manuals, to assist in providing information for
specific service operations.
When hoisting (or jacking) HSV models,
ensure that the lifting h ead of the hoist lifts on
the chassis before the arm of the hoist
contacts the side-skirt
