D Brakes Page D-1

Page D-1

Section D

Brakes

ATTENTION:

HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS consists of seat belt pre-

tensioners (fitted to all front seat s), a driver’s-side air bag, a passeng er’s-side air bag and left and right h and

side air bags. Refer to CAUTIONS, Section 12M Occupant Protection System in the MY 2005 VZ Series

Service Information before performing any service operation on or around SRS components, the steering

mechanism or wiring. Failure to follow the CAUTIONS could result in personal injury or unnecessary SRS

system repairs.

1 Purpose...................................................................................................................................................2

2 General Information ...............................................................................................................................3

Front........................................................................................................................................................................ 3

Rear......................................................................................................................................................................... 3

D Brakes Page D-2

Page D-2

1 Purpose

The purpose of this section is to provide information on the Brake System fitted to HSV VZ Murph Edition models.

NOTE:

If specific technical data on a HSV model is not

contained in this supplement, obtain data for that

model from Section 5A – Standard Brakes of the

VZ series Service Information. References are

made throughout this section to Holden Service

Information to assist in providing information for

specific service operations.

When hoisting (or jacking) HSV models,

ensure that the lifting h ead of the hoist lifts on

the chassis before the arm of the hoist

contacts the side-skirt

D Brakes Page D-3

Page D-3

2 General Information

The brake system fitted to HSV VZ Murph Edition model is the AP High Performanc e 6 piston system as fitted to HSV VZ

models with the only differences being colour coded Murph Orange front and rear c allipers and Silver finish front and rear

discs. For all service information on Murph Edition brakes refer to HSV VZ Clubsport R8 Serivce Information.

Whenever any component of the ABS is

disturbed during service operations, it is vital

that the complete ABS is checked using the

procedure detailed in the relevant Holden

Service Manual.

Front

PART NUMBER DESCRIPTION QUANTITY

HSV-05A-021203MU CALIPER ASM. FRT LH INC. PADS - YELLOW 1

HSV-05A-021204MU CALIPER ASM. FRT RH INC. PADS - YELLOW 1

HSV-05A-032813 DISC ROTOR – FRT – LH – NON DRILLED 1

HSV-05A-032814 DISC ROTOR – FRT – LH – NON DRILLED 1

HSV-05F-970706 HOSE – FRT BRAKE - RH 1

HSV-05F-970707 HOSE – FRT BRAKE - LH 1

442356 BOLT – BRAKE HOSE TO CALIPER 2

92138557 BOLT – FRT CALIPER TO KNUCKLE 4

Rear

PART NUMBER DESCRIPTION QUANTITY

HSV – 05B-021203MU CALIPER ASM. REAR LH INC. PADS - YELLOW 1

HSV – 05B-021204MU CALIPER ASM. REAR RH INC. PADS - YELLOW 1

HSV – 05B-032811 DISC ROTOR – REAR – LH – NON DRILLED 1

HSV – 05B-032812 DISC ROTOR – REAR – RH – NON DRILLED 1

HSV – 05F-970704 HOSE – REAR BRAKE 2

442356 BOLT – BRAKE HOSE TO CALIPER 2

92138387 BOLT – REAR CALIPER TO KNUCKLE 4
