Transmission Page F-1
Page F-1
Section F
Transmission
ATTENTION:
HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS consists of seat belt pre-
tensioners (fitted to all front seats), a driver’s-side air bag, a passenger’s-side air b ag and left and right hand
side air bags. Refer to CAUTIONS, Section 12M Occupant Protection System in the MY 2005 VZ Series
Service Information before performing any service operation on or around SRS components, the steering
mechanism or wiring. Failure to follow the CAUTIONS could result in personal injury or unnecessary SRS
system repairs.
1 Purpose...................................................................................................................................................2
2 Transmission - General Information ....................................................................................................3
Transmission Page F-2
Page F-2
1 Purpose
The purpose of this bulletin is to provide information on the transmission assemblies fitted to the HSV VZ Murph Edition
models. This information is designed to supplement the information contained in the Holden VZ and HSV VZ series
Service Manuals, and details are given where differences occur between the HSV models and standard Holden models.
NOTE:
If specific technical data on a HSV model is not
contained in this supplement, obtain data for that
model from the relevant Holden VZ series Service
Manual Supplement. References are made
throughout this section to Holden Service
Manuals, to assist in providing information for
specific service operations.
When hoisting (or jacking) HSV models,
ensure that the liftin g head of the hoist lifts on
the chassis before the arm of the hoist
contacts the side-skirt
Transmission Page F-3
Page F-3
2 Transmission - General
Information
Two types of transmission are available in the HSV Murph option. They are the T56 M12 six speed manual transmission
and the HMD 4L65E Turbohydramatic 4 speed automatic transmission.
Both these transmissions are described in the Holden VZ and HSV VZ Service Information.
For all service information on these transmissions refer to Holden VZ and HSV VZ Service Information.
