Fuel and Exhaust Systems Page G-1
Page G-1
Section G
Fuel And Exhaust Systems
ATTENTION:
HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS consists of seat belt pre-
tensioners (fitted to all front seats), a driver’s-side air bag, a passenger’s-side air bag and left and right hand side
air bags. Refer to CAUTIONS, Section 12M Occupant Protection System in the MY 2005 VZ Series Service
Information before performing any service operation on or around SRS components, the steering mechanism or
w i rin g. Failure to follow the CAUTIONS could result in personal injury or unnecessary SRS system repairs.
1 Purpose...................................................................................................................................................2
2 HSV Exhaust Systems General Information........................................................................................3
3 HSV Fuel Systems General Information ..............................................................................................4
Fuel and Exhaust Systems Page G-2
Page G-2
1 Purpose
The purpose of this supplement is to provide information on the fuel and exhaust systems fitted to the HSV VZ Murph Edition
models. This information is designed to supplement that given in the Holden VZ Service Information, and details are given
where differences occur between the HSV models, and standard Holden models.
NOTE:
If specific technical data on a HSV model is not
contained in this supplement, obtain data for that
model from the relevant HSV or Holden VZ series
Service Manual Supplements.
When hoisting (or jacking) HSV models, ensure
that the lifting head of the hoist lifts on the
chassis before the arm of the hoist contacts the
side-skirt
Fuel and Exhaust Systems Page G-3
Page G-3
2 HSV Exhaust Systems General
Information
The exhaust system fitted to the HSV VZ Murph Edition is the same as the HSV VZ Clubsport, therefore for all service and
repair information refer to HSV and Holden VZ Service Information.
Fuel and Exhaust Systems Page G-4
Page G-4
3 HSV Fuel Systems General
Information
All components of the fuel systems in HSV VZ models are standard Holden components. It follows that reference to the
appropriate Holden Service Manual Supplement is necessary when performing any servicing operation on these components,
except the sedan and utility fuel pumps, which have an up rated higher flow fuel pump.
