Wiring Diagrams – Gen IV (LS2) V8
ATTENTION:
HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS consists of seat belt pre-
tensioners (fitted to all front se ats), a dri ver’s-side air b ag, a p asseng er’s-side air b ag and left and right han d side
air bags. Refer to CAUTIONS, Section 12M Occupant Protection System in the MY 2005 VZ Series Service
Information or Section 12M Occupant Protection System in the MY 2005 WL Series Service Information before
performing any service operation on or around SRS components, the steering mechanism or wiring. Failure to
follow the CAUTIONS could result in personal injury or unnecessary SRS s ystem repairs.
1 General Information ...............................................................................................................................2
2 Electrical Schematics Contents............................................................................................................3
3 Module Location Charts ........................................................................................................................4
Electrically Operated Mechanical Devices........................................................................................................... 4
Inductors ................................................................................................................................................................ 4
Measurement, Display and Test Devices............................................................................................................. 4
Modules, Systems and Sub-Assemblies .............................................................................................................5
Motors..................................................................................................................................................................... 5
Power Supplies...................................................................................................................................................... 5
Semi Conductors................................................................................................................................................... 6
Switches ................................................................................................................................................................. 6
Transducers ........................................................................................................................................................... 6
12P Wiring Diagrams Page 12P-2
Page 12P-2
1 General Information
The information contained within this section details the circuits that are unique to the HSV VZ vehicle. T he y refer mainl y to
engine circuits related to the LS2 eng ine, engine controller, ABS 8.0 system and PIM. These wiring diagrams are based on
the Integrated Vehicle Electrical Design (IV ED) wiring diagrams. For any circuits not displayed in this section please refer to:
Section 12P Wiring Diagrams – VZ Series
Section 12P Wiring Diagrams – W L Series.
Additional wiring, wiring harness and specific wiring harness installation information. Please refer to:
Section 12O Fuses, Relays and Wiring Harness – VZ Series
Section 12O Fuses, Relays and Wiring Harness – WL Series
Further information on develo pin g a diagnostic procedure for electrical circuit diagnosis, electrical circuit test procedures,
diagnostic tests and wiring repair procedures is contained in Section 12 of the Holden VZ Service Information.
12P Wiring Diagrams Page 12P-3
Page 12P-3
2 Electrical Schematics Contents
System Wiring Diagram Descrip tio n Diagram Sheet No.
Brakes 012
Charge/Energy Store 027
Engine 001 to 009
Engine / transmission cool ing 017
Fuel Storage and Handl ing 013
HVAC 015
Integrating Function 018
Power & Gnd Distribution 011, 014, 016,
019 to 020,022,
023 to 024
Serial Data Link 021, 025 to 026
Transmission 010
12P Wiring Diagrams Page 12P-4
Page 12P-4
3 Module Location Charts
Electrically Operated Mechanical Devices
Component Code Location
Canister Purge Solenoid Valve Y123 005.17
Reverse Lock Out Solenoid Y144 006.46
Throttle Actuator Y38 008.08
Inductors
Component Code Location
Fuel Injector Solenoid L2 006.02
006.08
006.13
006.19
006.24
006.29
006.34
006.39
A/C Clutch Coil L7_AC_CL 015.28
Measurement, Display and Test Devices
Component Code Location
Instrument Cluster P3 007.51
026.26
12P Wiring Diagrams Page 12P-5
Page 12P-5
Modules, Systems and Sub-Assemblies
Component Code Location
Electronic Ignition Control A40 002.19
002.37
Transmission Control A112 010.28
004.54
026.27
Engine Control A43 026.50
001.28
002.28
003.28
004.28
005.28
006.28
007.28
008.28
Communication Interface A5 026.12
021.24
009.26
Electronic Brake and Traction Control A37 026.41
012.14
Body Control Module A15 026.12
Radio,Clock and CD Player A133 026.31
Serial Data Module A65 026.19
Motors
Component Code Location
Fuel Pump Motor M8 013.31
007.42
Engine Cooling Fans M7 017.33
Starter Motor M15 027.21
Power Supplies
Component Code Location
Generator G8 004.02
027.36
Battery G1 027.03
12P Wiring Diagrams Page 12P-6
Page 12P-6
Semi Conductors
Component Code Location
Engine Wiring Harness Fuse Block
Diode V5_AC_CC 015.37
Switches
Component Code Location
Stop Lamp, Traction Control and Cr uise
Control release Switch S220 007.21
Clutch Pedal Position Switch S42 007.35
Cruise Control Switch S43 010.37
009.26
PRNDL Switch S187
Electronic Traction Control Switch S73 012.46
Ignition & Start Switch S149 018.31
Transducers
Component Code Location
Mass Airflow Sensor B69 001.07
M.A.P. Sensor B67 001.25
Engine Oil Pressure Sensor B42 001.35
Engine Coolant Temperature Sensor B39 001.44
A/C Refrigeration Pressure Sensor B18 001.54
Heated Oxygen Sensor B57_LT_FR 003.04
Heated Oxygen Sensor B56_LT_RR 003.18
Heated Oxygen Sensor B166_RT_FR 003.30
Heated Oxygen Sensor B58_RT_RR 003.42
Knock Sensor B65 005.02
Knock Sensor B65 005.12
Camshaft Position Sensor B28 005.40
Crankshaft Position Sensor B30 005.52
Accelerator Pedal Position Sensor B22 008.28
Vehicle Speed Sensor B83 010.50
Front Wheel Speed Sensor B52_LT 012.02
Front Wheel Speed Sensor B52_RT 012.08
Rear Wheel Speed Sensor B76_LT 012.14
Rear Wheel Speed Sensor B76_RT 012.20
010.44
