Options & Accessories Page J-1
Page J-1
Section J
Options And Accessories
ATTENTION
HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS consists of seat belt pre-
tensioners (fitted to all front seats), a driver’s-side air bag , a passenger’s-side air bag and left and right side
air bags. Refer to CAUTIONS, Section 12M, of the Holden WL Service Information before performing any
service operation on or around SRS components, the steering mechanism or wiring. Failure to follow the
CAUTIONS could result in personal injury or unnecessary SRS system repairs.
1 Purpose...................................................................................................................................................2
2 HSV Sunroof ...........................................................................................................................................3
3 Fire Extinguisher....................................................................................................................................4
3.1 General Information............................................................................................................................................... 4
3.2 Service Operations................................................................................................................................................ 5
4 DVD Entertainment System...................................................................................................................6
5 HSV Tyre Pressure Monitors.................................................................................................................7
Options & Accessories Page J-2
Page J-2
1 Purpose
The purpose of this supplement is to provide information on the special options and accessories fitted to the HSV WL.
This information is designed to supplement that contained in the Holden WL Service Information, and details are given
where differences occur between the HSV models and standard Holden models. A series of instruction drawings detail
the design changes and indicate specific part numbers, fitting instructions and relevant notes for vehicle servicing.
NOTE
If specific technical data on a HSV model is not
contained in this supplement, obtain data for that
model from the relevant Holden WL Service
Information Supplement. References are made
throughout this section to Holden Service
Information, to assist in providing information for
specific service operations.
When hoisting (or jacking) HSV models,
ensure that the lifting h ead o f th e hoist lifts on
the chassis before the arm of the hoist
contacts the side-skirt
Options & Accessories Page J-4
Page J-4
3 Fire Extinguisher
3.1 General Information
HSV WL is fitted with a HSV design fire extinguisher. The extinguisher is located i n the rear luggage compartment.
Options & Accessories Page J-5
Page J-5
3.2 Service Operations
The fire extinguisher should be subjected to a regular visual inspection in accordance with the instructions on the
extinguisher. Particularly, the extinguisher should be inspected for damage and to ensure that the integral pressure
gauge registers the appropriate internal pressure. When discharged or when the internal pressure is outside the
prescribed limits, the extinguis hers shoul d be service d and re -char ged by an ap propriate supp lier. Ne w extinguishers ar e
available through the HSV spare parts systems.
Options & Accessories Page J-7
Page J-7
5 HSV Tyre Pressure Monitors
For all information relating to servicing an d repair of the HSV Tyre Pressure Monitor system refer to
Section 10 Wheels and Tyres , 2 General Information – Tyre Pressure Monitoring System in the Holden MY2005 W L
Service Information
