HOLDEN SPECIAL VEHICLES

SERVICE MANUAL SUPPLEMENT

SECTION D

BRAKES

CAUTION:

HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS consists of seat belt pre-

tensioners (fitted to all front seats), a driver’s-side air bag, a passenger’s-side air bag and left and right hand

side air bags. Refer to CAUTIONS, Section 12M Occupant Protection System in the MY 2005 VZ Series

Service Information before performing any service operation on or around SRS components, the steering

mechanism or wiring. Failure to follow the CAUTIONS could result in personal injury or unnecessary

SRS system repairs.

2

PURPOSE

The purpose of this section is to provide information on the Brake System fitted to HSV VZ SV6000 models.

NOTE:

If specific technical data on a HSV model is not contained in this supplement, obtain data for that model from

Section 5A – Standard Brakes of the VZ series Service Information. References are made throughout this section

to Holden Service Information to assist in providing information for specific service operations.

CAUTION:

When hoisting (or jacking) HSV models, ensure that the lifting head of the hoist lifts on the chassis before the arm

of the hoist contacts the side-skirt

3

BRAKES

1. GENERAL

The brake system fitted to HSV VZ SV6000 model is the AP High Performance 6 piston system as fitted to HSV

VZ models with the only differences being colour coded Devil Yellow front and rear callipers and Silver finish

front and rear discs. For all service information on SV6000 brakes refer to HSV VZ Clubsport R8 Service

Information.

CAUTION:

Whenever any component of the ABS is disturbed during service operations, it is vital that the complete ABS is

checked using the procedure detailed in the relevant Holden Service Manual

BRAKE PART NUMBERS

FRONT

PART NUMBER

DESCRIPTION

QUANTITY

HSV-05A-021203MU CALIPER ASM. FRT LH

INC. PADS - YELLOW

1

HSV-05A-021204MU CALIPER ASM. FRT RH

INC. PADS - YELLOW

1

HSV-05A-032813

DISC ROTOR – FRT – LH – NON DRILLED

1

HSV-05A-032814

DISC ROTOR – FRT – LH – NON DRILLED

1

HSV-05F-970706

HOSE – FRT BRAKE - RH

1

HSV-05F-970707

HOSE – FRT BRAKE - LH

1

442356

BOLT – BRAKE HOSE TO CALIPER

2

92138557

BOLT – FRT CALIPER TO KNUCKLE

4

REAR

PART NUMBER DESCRIPTION QUANTITY

HSV – 05B-021203MU CALIPER ASM. REAR LH

INC. PADS - YELLOW

1

HSV – 05B-021204MU CALIPER ASM. REAR RH

INC. PADS - YELLOW

1

HSV – 05B-032811 DISC ROTOR – REAR – LH – NON DRILLED 1

HSV – 05B-032812 DISC ROTOR – REAR – RH – NON DRILLED 1

HSV – 05F-970704 HOSE – REAR BRAKE 2

442356 BOLT – BRAKE HOSE TO CALIPER 2

92138387 BOLT – REAR CALIPER TO KNUCKLE 4
