HOLDEN SPECIAL VEHICLES
SERVICE MANUAL SUPPLEMENT
SECTION F
TRANSMISSION
CAUTION:
HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS consists of
seat belt pre-tensioners (fitted to all front seats), a driver’s-side air bag, a passenger’s-side air
bag and left and right hand side air bags. Refer to CAUTIONS, Section 12M Occupant
Protection System in the MY 2005 VZ Series Service Information before performing any
service operation on or around SRS components, the steering mechanism or wiring. Failure
to follow the CAUTIONS could result in personal injury or unnecessary SRS system repairs.
.
2
SERVICE MANUAL SUPPLEMENT
PURPOSE
The purpose of this bulletin is to provide information on the transmission assemblies
fitted to the HSV VZ SV6000 models. This information is designed to supplement the
information contained in the Holden VZ and HSV VZ series Service Manuals, and
details are given where differences occur between the HSV models and standard
Holden models.
NOTE:
If specific technical data on a HSV model is not contained in this supplement, obtain
data for that model from the relevant Holden VZ series Service Manual Supplement.
References are made throughout this section to Holden Service Manuals, to assist in
providing information for specific service operations.
CAUTION:
When hoisting (or jacking) HSV models, ensure that the lifting head of the hoist lifts
on the chassis before the arm of the hoist contacts the side-skirt
3
1. GROUP 7- TRANSMISSION - GENERAL INFORMATION
Two types of transmission are available in the HSV SV6000. They are the T56 M12
six speed manual transmission and the HMD 4L65E Turbohydramatic 4 speed
automatic transmission.
Both these transmissions are described in the Holden VZ and HSV VZ Service
Information.
For all service information on these transmissions refer to Holden VZ and HSV VZ
Service Information.
