1
HOLDEN SPECIAL VEHICLES
SERVICE MANUAL SUPPLEMENT
SECTION J
OPTIONS AND ACCESSORIES
CAUTION:
HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS consists of seat
belt pre-tensioners (fitted to all front seats), a driver’s-side air bag, a passenger’s-side air bag and
left and right hand side air bags. Refer to CAUTIONS, Section 12M Occupant Protection System
in the MY 2005 VZ Series Service Information before performing any service operation on or
around SRS components, the steering mechanism or wiring. Failure to follow the CAUTIONS
could result in personal injury or unnecessary SRS system repairs.
2
SERVICE MANUAL SUPPLEMENT
PURPOSE
The purpose of this supplement is to provide information on the special options and accessories
fitted to the HSV VZ SV6000 model. This information is designed to supplement that contained in
the Holden VZ series Service Manuals, and details are given where differences occur between the
HSV models and standard Holden models. A series of instruction drawings detail the design
changes and indicate specific part numbers, fitting instructions and relevant notes for vehicle
servicing.
NOTE:
If specific technical data on a HSV model is not contained in this supplement, obtain data for that
model from the relevant Holden VZ series Service Manual Supplement. References are made
throughout this section to Holden Service Manuals, to assist in providing information for specific
service operations.
CAUTION:
When hoisting (or jacking) HSV models, ensure that the lifting head of the hoist lifts on the chassis
before the arm of the hoist contacts the side-skirt
3
1. HSV SUNROOF
Refer to Section 1F of Holden VZ Service Information.
4
2. FIRE EXTINGUISHER
2.1 General. HSV VZ SV6000 models are fitted with a HSV design fire extinguisher.
For all information on the fire extinguisher refer to HSV VZ Service Information
Section J
5
1. HSV EMBEDDED SECURITY SYSTEM.
1.1 General.
The new HSV Embedded Security System (ESS) is fitted as standard equipment to all HSV VZ
series Vehicles. For all information on the SV6000 ESS System refer to HSV VZ Service
Information Section J
6
HSV REAR ENTERTAINMENT SYSTEM
General
HSV VZ SV6000 vehicles can be optioned with a Rear entertainment system. For all information on
the Rear Entertainment System refer to HSV VZ Service Information Section J
7
HSV TYRE PRESSURE MONITORS
The HSV SV6000 is fitted with Tyre Pressure Monitors. For all information on the SV6000 Tyre
Pressure Monitor system refer to HSV VZ Service Information Section J
