Telephone/Telephone - Cellular Phone Connection
Sheet
047 of 078
V05C _12PSHT047(AU)
MY2005 VZ COUPE
.00 .01 .02 .03 .04 .05 .06 .07 .08 .09 .10 .11 .12 .13 .14 .15 .16 .17 .18 .19 .20 .21 .22 .23 .24 .25 .26 .27 .28 .29 .30 .31 .32 .33 .34 .35 .36 .37 .38 .39 .40 .41 .42 .43 .44 .45 .46 .47 .48 .49 .50 .51 .52 .53 .54 .55 .56
061.12
F.B.H
151
BK/GN
X157
YE
F.B.H
2506
F.B.H
43
X129057.16X129058.02
BU
042.22 A133
F.B.H
1040
OG/BK
A133042.26042.17 A133
VOC_SIG
5X1
Mobile Tel & Nav Ant Harn
Inline-To Rdo &
Connector
X155
ACC
3X1
BATT
1X1
GND
2X1
MUT_SIG
4X1
VOC_RET
6X1
F.B.H
YE/BK
655
F.B.H
BU/BK
5211
A133 - RADIO
X155 - CELL PHONE CONN
HOT AT ALL TIMES HOT IN ACCY OR RUN
