W ashers, Wipers and Horn Page 12N–1

19-NOV-2002 Page 12N–1

Section 12N

Washers, Wipers and Ho rn

ATTENTION

Before performing any Service Operation or other procedure described in this Section, refer to Section 00

WARNINGS, CAUTIONS AND NOTES for correct workshop practices with regard to safety and/or property

damage.

1 General Information............................................................................................................................... 2

1.1 Electrical Diagnosis...............................................................................................................................................2

1.2 Reservoir Assembly...............................................................................................................................................3

1.3 Horn.........................................................................................................................................................................4

1.4 Fuse, Relay and Wiring Harness...........................................................................................................................5

W ashers, Wipers and Horn Page 12N–2

19-NOV-2002 Page 12N–2

1 General Information

With the following exceptions, MY 2004 WK Series Washers, Wipers and Horn information carries over from MY 2003

VY Series vehicles. For information not contained within this Section, refer to Section 12N WIPERS, WASHERS AND

HORN, in the MY 2003 VY and V2 Series Service Information.

1.1 Electrical Diagnosis

When performing electrical diagnosis on the washers, wipers or horns, for all body control module information, refer to

Section 12J, BODY CONTROL MODULE in the MY 2004 WK Service Information.

W ashers, Wipers and Horn Page 12N–3

19-NOV-2002 Page 12N–3

1.2 Reservoir Assembly

When performing service operations on the reservoir assembly that require the removal of wheels and tyres, refer to

Section 10, WHEELS AND TYRES in the MY 2004 WK Service Information.

W ashers, Wipers and Horn Page 12N–4

19-NOV-2002 Page 12N–4

1.3 Horn

When performing service operations on the horns, for information on the front bumper fascia assembly removal and

reinstallation, refer to Section 1D BUMPER BARS in the MY 2004 WK Service information.

W ashers, Wipers and Horn Page 12N–5

19-NOV-2002 Page 12N–5

1.4 Fuse, Relay and Wiring Harness

For all fuse, relay and wiring harness information, refer to Section 12O Fuses, Relays and Wiring Harnesses in the

MY 2004 WK Service Information.
