SECTION I – ELECTRICAL AND INSTRUMENTS

CAUTION:

HSV vehicles are equipped with a Supplemental Restraint System (SRS). An SRS consists of seat belt

pre-tensioners (fitted to all front seats), and a driver’s side air bag or a driver’s side airbag AND a

passenger’s-side air bag and left and right hand side air bags. Refer to CAUTIONS, Section 12M , of the

Holden VS Series Service Information or Section 12M, of the VT Series II Service Information before

performing any service operation on or around SRS components, the steering mechanism or wiring.

Failure to follow the CAUTIONS could result in personal injury or unnecessary SRS syste m repairs.

PURPOSE

The purpos e of th is s upplem ent is to pro vide inform ation on the HSV electr ica l and ins trum ent acces sories f itted t o

the HSV VT Series II, VS & WH models. The information is designed to supplement that given in the Holden VT

Series II and VS Series Service Information and details are given where differences occur between the HSV

models, and standard Holden models. A series of instruction drawings describe the design changes and indicate

specific part numbers, fitting instructions and relevant notes for vehicle servicing.

NOTE: If specific technical data on a HSV model is not contained in this supplement, obtain data for that model

from the VS Ser i es Ser vic e Inf or mation, VT Se rie s II Se rv ice Information or th e WH Serie s Serv ice Inform ation.

References are made throughout this section to Holden Service Information, to assist in providing information for

specific service operations.

CAUTION: When hoisting (or jacking) HSV models, ensure that the lifting head of the hoist lifts on the chassis

before the arm of the hoist contacts the side-skirt

INSTRUMENTATION

1. GENER AL: A special Instrument Clust er designed by HSV is f itted to all HSV VT 2, VS & W H vehicles, except

VT1 XU8. The cluster includes a HSV speedometer with an operating range extending to 250 km/h. The cluster

incorporates a mid-grey face, red needles and warning lights and, when illuminated, green numerals and letters.

HSV GTS is fitted with an upshift indicator . This indicator is contr olled b y the Eng ine Control Unit and t he LED an d

buzzer giving the driver an indication when to upshift to achieve maximum performance. The shift indicator will

operate:

• When engine coolant is <85°C at 4,000 RPM.

• When engine coolant is >85°C:

− 1

st 6,050 RPM

− 2

nd 6,200 RPM

− 3

rd 6,300 RPM

− 4

th 6,300 RPM

− 5

th 6,300 RPM

The harness has an inline fuse (3A) which is located underneath the glove compartment near the firewall. The

power feed for the indicator is fused by F12, turn signal (15A). Ref. Figure I-1.

2. As a running change through VT2 models the tachometer redline has been changed to suit particular engine

specifications - refer table below.

Engine Tachometer Red Line

S/C XU6 5,500 rpm

LS1 Auto & Manu al 6,000 rpm

GTS 6,500 rpm

3. SERVICE OPERATIONS: The HSV instrument cluster and the standard Holden VT2 cluster use the same

mounting fixtures and fasteners. Remove, service and refit the HSV instrument cluster in accordance with the

procedures detailed in Section 12C - Instruments, Wipers/Washers & Horn of the VT Series II Service

Information.

ELECTRICAL FACILITIES

The various special HSV options fitted to the VT2, VS & WH range of vehicles, often require that special or

additional electric harnesses be installed. Some of these HSV harnesses are fitted during vehicle build-up at the

Holden factory and other smaller harnesses (often called ‘a patch harness’) are fitted at the HSV facility when the

electrical option is being installed. A summary of these electrical harnesses is included to facilitate service, repair

and retro-fitment of the HSV options.

PART No DESCRIPTION

12H2970801 Level Ride Patc h Har ness

(fitted to all Senators)

12H3970701 Speedo Modul e Har nes s

(Fitted to 220 manual only)

12H-990302 Sunroof Harness

12H-970801 Electrochromatic Mirror harness

(fitted to all Senator Signatures and all vehicles with Sunroof)

12L971016 Harness - Diversity Amplifier (Estate only)

12H-971006 Console Illuminating Patch (Estate)

12H2970202 Level Ride Patc h (No n Sena tors )

12H-971005 Door Courtesy Lamp Patch Harness Kit

92078950 ClubSport & XU6 Main Wiring Harness with ESS

92076133 Senator, Sen ator Si gna tur e, Se nator Sign atur e Es tat e Main

W iring Harness with ES S

92080902 Grange Main Wiring Harness with ESS

92085497 Grange Roof Lamp Harness

92078317 Senator Sig nat ur e Body Control Module

92080633 Grange Body Control Module

12L-9916 07 ESS (Em bedde d Sec urity System)

12H-990704 Harness Shift Indicator
