SECTION E – HSV 255 KW & 300 KW ENGINE
IMPORTANT:
Before performing any Service Operation or other procedure described in this Section, refer to Section 00
CAUTIONS AND NOTES for correct workshop practices with regard to safety and/ or property damage.
1. HSV 255 KW & 300 KW ENGINE
1.1 ENGINE MECHANICAL
The engin e mechanic als for HSV GT O Coupe Models fitted with HSV 25 5 kW engine carr y over f rom the HSV VX
Series Clubsport Models. For HSV GTS Coupe Models fitted with HSV 300 kW C4B engine carry over from the
HSV VX Series GTS Sedan Models.
For information relating to the engine mechanicals for HSV GTO Coupe Series Models fitted with HSV 255 kW
engine, refer to Section E - ENGINE in the HSV VX Clubsport Series Service Information in conjunction with
Section 6A3 - ENGINE MECH ANIC AL - GEN III V8 ENGINE in the Holden VT Series II Service Information.
For inf ormation r elat in g to t he en gi ne mechanic als f or HSV G T S Cou pe Ser i es M ode ls f itted with H SV 300 kW C4B
engine, refer to Section E - ENGINES of the HSV VTII Series Workshop Information.
Techline
Techline
Techline
1.2 ENGINE COOLING
The engine cooling system for HSV GTO Coupe Models fitted with HSV 255 kW engine carry over from the HSV
VX Series Clubsport Models.
For information relat ing to the eng ine cooling for HSV GTO Coupe Series Models fitted with HSV 255 kW engine,
refer to Section E - ENGINE in the HSV VX Clubsport Series Service Information in conjunction with
Section 6A3 - ENGINE MECH ANIC AL - GEN III V8 ENGINE in the Holden VT Series II Service Information.
1.3 POWERTRAIN MANAGEMENT
The powertrain m anagement system for HSV GTO Coupe Models fitted with HSV 255 kW engine carry over from
the HSV VX Series Clubsport Models.
The powertrain management system for HSV GTS Coupe fitted with HSV 300 kW engine carries over from the
HSV VX Series GTS Sedan Models.
For inf ormation rel ati ng to t he Po wertr a in Ma nag ement f or HSV GTO Coupe Series Mod els f itt ed with HS V 255 kW
engine, refer to Section E - ENGINE in the HSV VX Clubsport Series Service Information in conjunction with
Section 6C3 - POWERTRAIN MANAGEMENT - GEN III V8 ENGINE in the Holden VT Series II Service
Information.
1.4 CHARGING SYSTEM
The Mits ubishi 140 am p Gener ator, f itted to all H SV GT O Coupe Models f itted with HS V 255 kW engine and HS V
GTS Coupe fitted with HSV 300 kW engine carries over from the Holden VT Series II Models.
For inf ormation relati ng to the char ging system for HSV GT O Coupe Series Models f itted with HSV 255 kW engine
and HSV GT S Coupe fitted with HS V 300 kW engine, refer to Sect ion 6D3- 1 - CHARGI N G SY STEM - GEN III V8
ENGINE in the Holden VT Series II Service Information.
1.5 STARTING SYSTEM
The Delco Remy, 6 pole, 4 brush starter motor, fitted to all HSV GTO Coupe Models fitted with HSV 255 kW engine
and HSV GTS Coupe fitted with HSV 300 kW engine carries over from the Holden VT Series II Models.
1.6 IGNITION SYSTEM
The ignition system fitted to all HSV GTO Coupe Models fitted with HSV 255 kW engine and HSV GTS Coupe fitted
with HSV 300 kW engine carries over from the Holden VX Series I Models.
For information relating to the ignition system for HSV GTO Coupe Series Models fitted with HSV 255 kW engine
and HSV GTS Coupe fitted with HSV 300 kW engine, refer to Section 6D3-3 - IGNITION SYSTEM - GEN III V8
ENGINE in the Holden VX Seri es I Ser vice Infor mation, in co njuncti on with Se ction 6D3-3 - IGNIT ION SYST EM -
GEN III V8 ENGINE in the Holden VT Series II Service Information.
1.7 EMISSION CONTROL
The emission control system for HSV GTO Coupe Models fitted with HSV 255 kW engine and HSV GTS Coupe
fitted with HSV 300 kW engine carries over from the Holden VX Series I Models.
For inf orm ation rel ating to the em is sion con trol s ystem for HSV GT O Coup e Seri es Models fitte d with H SV 2 55 kW
engine and HS V GTS Coupe fitted with HS V 300 kW engine, refer to Section 6E3 - EM ISSION CONTROL- GEN
III V8 ENGINE in the Holden VX Series I Service Information, in conjunction with Section 6E3 - EMISSION
SYSTEM - GEN III V8 ENGINE in the Holden VT Series II Service Information.
1.8 ENGINE TUNE
Engine tuning is simplified by electronic control of both the air/fuel mixture and ignition timing by the Powertrain
Control module (PCM), which controls the ratio of the air/fuel mixture to near optimum condition.
For inf orm ation rel ating to the em is sion con trol s ystem for HSV GT O Coup e Seri es Models fitte d with H SV 2 55 kW
engine and HSV GTS Coupe fitted with HSV 300 kW engine, refer to Section 6F3 – ENGINE TUNE- GEN III V8
ENGINE i n the Holden VX Seri es I Service I nform ation, in conju nction with Section 6F3 – ENGINE T UNE - GEN
III V8 ENGINE in the Holden VT Series II Service Information.
2. CLUTCH – HSV 255 KW AND 300 KW ENGINE
2.1 GENERAL INFORM ATION
The clutch and operating system used for HSV GTO and GTS Coupe Series Models equipped with the HSV 255
kW and 300 kW engine and manual transmission carries over from Holden VX Series Models.
For inf orm ation r e lat ing to t he c lutch fitted to H S V G TO and G T S Coup e Series Mode ls eq uip pe d with HS V 255 kW
and 300 kW engine, refer to Section 7A2 – CLUTCH, in the Holden VX Series Service Information in conjunction
with Section 7A1 – CLUTCH, in the Holden VT Series II Service Information.
